Operating characteristics/technical data:
Annual energy consumption: 28.4 kWh
Energy efficiency class: B
Fluid dynamic efficiency: 14.9
Fluid dynamic efficiency class: D
Lighting efficiency: B
Grease separation efficiency: 77.3
Grease separation efficiency class: C
Airflow at minimum / maximum speed in normal operation: 216.9 m³/h / 330.1 m³/h
Airborne noise emission at minimum / maximum speed in normal operation: 57 dB / 64 dB
Equipment features:
Operation via push buttons
Stainless steel housing and shaft
Speed levels: 3
Lighting max. 1 x 2.5 W LED
Tube connection (diameter): 150 mm
Voltage / frequency: 220-240V / 50 Hz
Connected power: 67.5 W
Metal grease filter 2 x
Dimensions:
Device dimensions in cm (H x W x D) / weight in kg: 58-96 x 60 x 47.5 / 6.7
With packaging (H x W x D) / Weight in kg: 52 x 65 x 24.2 / 8.7
